JHV V type HEPA filter
  • 品牌:
  • 发布时间:2023-12-25 21:54:25
  • 产品点击:361

V-type large air volume filter, with ABS injection molded plastic frame (fixed standard size) and metal frame (non-standard customized size) as its frame, adopts V-type structure, which is st

请选择业务咨询方式

  • 手机

    +8615901736546

  • 电话咨询

    +86 400 698 0996

  • 咨询 & 报价

产品详细 咨询 & 报价

JHV V type HEPA filter

frame: ABS engineering plastic outer frame (galvanized frame or stainless steel outer frame can be customized)

Filter material: superfine glass fiber; High dust capacity, low resistance

Efficiency: (EN779:2002) H10, H13, H14

(ASHRAE 52.2:2007)MERV16,MERV17,MERV19

Dimension (mm): 595 * 595 * 292595 * 295 * 292495 * 495 * 292610 * 610 * 292.

Application:

It is mainly used for large air volume air conditioning purification equipment, such as medium efficiency filtration and terminal filtration of air conditioning box system.

Common specifications


Model

W x H x D

Dimensions

W x H x D(mm)


Structure


Frame

Media Area

(m²)

Rated Air Flow

(m³/h)

Initial Pressure Drop(Pa)

H10   H13  H14

JHV1212-2V

287X287X292


2V

4.2

800



180   249   280

JHV1220-2V

287X490X292

塑框/金属框

7.7

1200

JHV1224-2V

287X592X292


9.4

1600

JHV2012-3V

490X287X292

3V

6.4

1000

JHV2020-3V

490X490X292

塑框/金属框

11.6

1800

JHV2024-3V

490X592X292


14.4

2200

JHV2412-3VF

592X287X292

3V

6.4

1100

JHV2420-3V

592X490X292

塑框/金属框

11.6

1900

JHV2424-3V

592X592X292


14.4

2400

JHV2412-4V

592X287X292

4V

8.4

1600

JHV2420-4V

592X490X292

塑框/金属框

15.4

2500

JHV2424-4V

592X592X292


18.8

3200

JHV2412-5V

592X287X292

5V

10.5

1800

JHV2420-5V

592X490X292

塑框/金属框

19.0

3200

JHV2424-5V

592X592X292


23.5

3900



  1. In case of changes in specifications, structure and performance, the latest data provided by our company shall prevail

  2. The company accepts orders of non-standard specifications
